TEKNİK ÖZELLİKLER
| ÖZELLİK | MAYGALE 23 |
| Working height | 22,85 m |
| Platform height | 20,85 m |
| Min. Floor haight | 0,39 m |
| Horizontal reach | 11,00 m |
| Lift capacity | 230 kg |
| Ground bearing pressure on tracks | 136 kN/m2 |
| Max.wind speed | 45 km/h |
| Platform width | 1,19 m |
| Length - storage | 5,54 m |
| Height | 1,93 m |
| Length | 6,68 m |
| Wheelbase | 1,42 m |
| Platform depth | 0,73 m |
| Ground clearance centre | 0,17 m |
| Track | 0,72 m |
| Track width | 0,23 m |
| Surface with outriggers | 3,97 x 3,92 m |
| Max. slope (lengthways) | 32% |
| Max.ground bearing pressure on levelling jacks | 167 kN/m2 |
| Diesel engine | KUBOTA |
| Fuel tank capacity | 25 L |
| Hydraulic tank capacity | 60 L |
| Power | 12,5 kW @ 3600 tr/mn |
| Weight /4x4x4 | 3450 kg |
